| Place of Origin | Hunan, China |
| Brand Name | ZH brand |
| Certification | ce |
| Model Number | egg tray/carton machine |
Capacity and product pictures
|
Type of products |
30-cell egg tray |
12-cell egg carton/box |
10-cell egg carton/box |
6+6- cell egg carton/box |
6-cell egg carton/box |
Fruit tray |
Coffee tray |
|
capacity (PCS/HR) |
2000 |
2000 |
2000 |
2000 |
4000 |
1200 |
2800 |
Remarks: The capacity calculation takes the production of 30 cavity egg trays as the standard.(Size 310X290MM, weight 60-70g)
|
Power list (Full Auto ET2000B) |
|||||
| NAME AND TYPE | QUANTITY | POWER (KW) |
REMAKR | ||
| Pulping system | 1 | FZ-600-6000 Conveyor | 1 | 1.5 | |
| 2 | ZGS-1 Hydrapulper | 1 | 22 | ||
| 3 | ZSK-0.9 Vibration Screen | 1 | 3 | ||
| 4 | Agitator | 2 | 4.4 | 2.2kw/set | |
| 5 | Water Pump 1 | 1 | 5.5 | 5.5kw/set | |
| Stock Pump | 1 | 6 | 3kw/set | ||
| 6 | Water Pump 2 | 1 | 2.2 | ||
| 9 | High pressure water pump | 1 | 3 | ||
| 10 | High pressure washer | 1 | 3 | ||
| Forming System |
11 | E2000 Automatic Forming Machine |
1 | 5.5 | |
| 12 | Water-ring Vaccum Pump | 1 | 45 | ||
| 14 | Filter Pump | 1 | 5.5 | ||
| 15 | Air Compressor | 1 | 11 | ||
| Drying Systerm |
17 | Drying Line | 1 | 15 | |
| Total Power | 132.6 | ||||
| Consumption List (Full-Auto ET2000) | |||
| NO. | DESCRIPTION | CONSUMPTION PER HOUR | REMARK |
| 1 | Waste Paper | 140kg | |
| 2 | Electricity | 90kw | |
| 3 | Water | 0.5T | |
| 4 | 0# Diesel Oil | 24kg | choose anyone from the three |
| Natural Gas | 30m³ | ||
| LPG | 24kg | ||
| Fuel combustion values | 10000K CARL/ kg for Diesel Oil | Energy Consumption of No.4 is counted with these data. | |
| 8000K CARL/m³ for Natural Gas | |||
| 10000k CARL/ kg for LPG | |||
ZH Molded Pulp Co., Ltd is specialized in manufacturing pulp molding machines, the first pulp molding machine supplier found in 1986.
Through 20 year’s experience, our company has a professional team in designing, manufacturing, and after-sale service. Our team has know the most advanced technology well in pulp molding machines, which have the types of reciprocating machine, rotary machine. In 2008, we developed an energy-saving, small-space multi-layers drying line, popular in domestic and abroad. Our machine has been sold well at home and abroad such as South America, Africa, Russia, and Middle-East area, in the quality of energy-saving, advanced design, and reasonable cost.
| Model | Capacity | Automation | Dryer | Forming Type |
|
ET600(click to view more) |
600pcs/hour |
Semi auto |
No |
Reciprocating |
|
E1000(click to view more) |
1000pcs/hour |
Semi auto |
No |
Reciprocating |
|
E2000(click to view more) |
2000pcs/hour |
full auto |
multilayer |
Rotary |
|
E3000(click to view more) |
3000pcs/hour |
full auto |
multilayer |
Rotary |
|
E4000(click to view more) |
4000pcs/hour |
full auto |
multilayer |
Rotary |
|
E8000(click to view more) |
8000pcs/hour |
full auto |
multilayer |
Rotary |
|
E10000(click to view more) |
10000pcs/hour |
full auto |
multilayer |
Double Rotary |
|
E15000(click to view more) |
15000pcs/hour |
full auto |
multilayer |
Double Rotary |
Semi-auto reciprocating egg tray Machine Full Automatic Tableware Machine Double Rotary egg tray Machine
400pcs / hr -1000 pcs /hr 8000- 100000 pcs / hr
